250-50 Kn/m Reinforce Uniaxial Polyester Geogrid Dam And Slope
River Bank Embankment Stabilization
Yixing Shenzhou 250-50 Polyester Geogrids Technical characteristics
and advantages :
Mechanical properties: 250 KN/m high tensile strength in the
longitudinal direction, 50 KN/m auxiliary support in the transverse
direction, to achieve asymmetric structural design, suitable for
scenes with clear main force direction
Durability: Polyester fiber is resistant to acid and alkali
corrosion, UV aging, and has a service life of more than 50 years
Convenience of construction: The roll form supports rapid laying,
tightly combined with the soil, and no complex anchoring is
required
Typical engineering case reference:
1.Extension of expressways: 250-50 KN/m specifications are used in
shoulder areas with lower transverse strength requirements, and the
longitudinal main reinforcement bears 10 of the vehicle load.
2. River ecological slope protection: Used with a three-dimensional
vegetation net, the transverse strength meets the shallow soil
fixation requirements
Yixing Shenzhou Polyester Geogrids :
UX Uniaxial Polyester Geogrids:
Stronger in one direction, used for reinforcement in specific
directions, such as retaining walls.
BX Biaxial Polyester Geogrids:
Strong in both directions, suitable for applications requiring
reinforcement in all directions, like embankments and slopes.
250-50KN/M PET Uniaxial Polyester Geogrids Technical Specification
(ASTM/ISO Standards)
| Property | 100 kN/m | 200 kN/m | 300 kN/m | Test Method |
|---|
| Tensile Strength (MD) | ≥100 kN/m | ≥200 kN/m | ≥300 kN/m | ASTM D6637 / ISO 10319 |
| Elongation at Break | ≤13% | ≤13% | ≤13% | ASTM D6637 |
| Creep Limit (50 yrs) | ≤2% | ≤2% | ≤3% | ISO 13431 |
| Aperture Size | 25.4*25.4mm / 50.8*50.8mm | 25.4*25.4mm / 50.8*50.8mm | 25.4*25.4mm / 50.8*50.8mm | - |
Packing and Shipping
Selling packing: Customers' company Logo mark can be designed and added.
Outer packing: Packed in double layer woven bags to ensure smooth arrival and
avoid rough handle.
Delivery Detail: Winthin 10 days after received your deposit
Delivery Detail: 100,000 square meters can be finished within 3 days
Delivery Time: 3-20 days after confirming order, detail delivery date should be
decided according to production season and order quantity.
Strict Quality Control :
SHENZHOU Geosynthetics has established advancing laboratory in
China for internal inspecting. We founded strict quality control
system from raw material to finished products testing. As national
high tech eterprise, we obtained ISO9001:2008 & ISO14001:2004
quality & environment management system certification.
With top quality and professional management, we passed the CE
certificate and Bureau Veritas Certification and SGS Certification.
PET Uniaxial Polyester Geogrids Application :
1. Reinforced Soil Retaining Walls
Heights up to 40m
Reduces required concrete by 60%
2. Steep Slope Stabilization
Angles up to 70°
Prevents landslides in mountainous terrain
3. Transportation Infrastructure
Bridge approach embankments
High-speed railway foundations
4. Mining & Heavy Industry
Tailings dam reinforcement
Haul road stabilization
5. Coastal Protection
Revetment base reinforcement
Breakwater anchoring systems
For more expertise and solutions For 100-30KN Polyester Geogrids,
please contact Yixing Shenzhou !
